Technical Specifications
Show:
All
Differences
Features
-
Store up to 198 Bordeaux Style Bottles
-
Adjustable/Repositionable Shelves
-
Double-Glazed Door with Anti-UV Glass
-
LED Digital Display Panel
-
Humidity Recycling System
-
Security Lock
-
Reversible Door (by technician only)
-
Extra Wide Shelf Cradles
-
Reversible Shelves
-
Inverter Compressor
-
Wine Display Shelf
-
Soft Close
-
Double-Glaze Door with Anti-UV Glass
-
Top-to-Bottom LED Lighting
-
Audio and Visual Alert
-
Winter Function for Cold Climates
-
Cut-Off Thermostat
-
Dedicated Cellaring Mode
-
Aluminium Reinforced Shelves
-
Door Stop
DIMENSIONS & WEIGHT
-
Air space at sides (mm)40 60
-
Air space above cabinet (mm)50 50
-
Weight Unloaded84 85
-
Weight Loaded254
-
Rear Spacer (mm)30
-
Height (mm)1860 1860
-
Width (mm)595 595
-
Depth (mm)610 610
-
Joinery cut out dimension- minimum height (mm)1910 1910
-
Joinery cut out dimension- minimum width (mm)635 655
-
Joinery cut out dimension- minimum depth (mm)640 640
-
Depth Door Open (mm)1200
-
Door depth including seal (mm)55
CABINET FEATURES
-
Display PanelLED Digital Display LED Digital Display
-
Castors and Feet2 Front Adjustable Feet, 2 Back Castors 4 Adjustable Feet
-
Internal HeaterYes Yes
-
LockYes Yes
-
AlarmAudio & Visual Audio & Visual
-
LightingWhite LED White LED
-
Number of Shelves6 6
-
Shelving MaterialAmerican oak American Oak with metal front
-
Shelving Type4 Full adjustable, 1 display, 1 ¾ shelf 4 Full adjustable, 1 display, 1 ¾ shelf
PRODUCT PROFILE
-
Domestic warranty details (yrs)2 2
-
Installation TypeBoth Both
-
FinishBorderless Black Glass Borderless Black Glass
-
Door TypeGlass Door Glass Door
-
Door ConstructionDouble Glazed, UV Treated Double Glazed, UV Treated
-
HandleRecessed Recessed
-
Fridge door openingRight Right
-
RefrigerantR600a R600a
-
Easy Capacity (Bottles)130 130
-
Max Capacity (Bottles)198 198
-
Main FunctionServe a wide range of varietals Serve a wide range of varietals
-
Alternate FunctionCellar red & white wine Cellar red & white wine
-
No of Zones1 or Multi 1 or Multi
-
Temperature Range Zone 1 (deg)Top: 8 - 18 Degrees C 5 - 20 Degrees C
-
Temperature Range Zone 2 (deg)Bottom: 5 - 12 Degrees C
PERFORMANCE
-
Power Supply240V / 10AMP 240V / 10AMP
-
Electricity Consumption (kWh/Day)1 1
OTHER
-
RangePremium
Wine Cellars
-
Temperature Range Zone 3 (deg)Single Zone: 8 - 18 Degrees C
